Audience
Professionals wanting a tool to automate their entire CAD-based CMM programming process
About MiCAT Planner
MiCATPlanner enables more flexible measurement by complying with customizable measuring rules that can be set as needed. Depending on the feature type, size, and other criteria, the operator sets the number of measuring points, their distribution, and speed for touch-trigger or scanning probes. Several sets of rules may be applied simultaneously according to manufacturing or customer requirements. Save up to 95 percent on CMM part program creation time. Reduce parts programming labor costs. Minimize potential costly and damaging probe collisions. Ensure maximum efficiency with a virtual pre-run measurement program. Select characteristics, features, and measurement point sets to include or exclude from the measurement plan. Automatically apply individual or global measurement strategies for all part programs or specific programs. Explain features that can’t be measured like missing GD&T, probe angle not defined, etc.
Other Popular Alternatives & Related Software
ZEISS CALYPSO
ZEISS CALYPSO measures geometrical elements simply, quickly and reliably. Just click the desired features to configure inspection plans. Combined with ZEISS measuring systems and sensors, you will have a powerful one-stop system. The software will also adjust to your demands. Due to numerous optional add-ons, ZEISS CALYPSO also offers the right tools for special requirements. Create inspection plans with just a few simple clicks and without any programming skills. ZEISS CALYPSO is programmed directly at the workpiece or graphically at the CAD design. Optional add-ons allow you to create and store entire CNC inspection plans on a remote workstation. ZEISS CALYPSO automatically creates inspection plans based on PMI data including all relevant features and characteristics. With the integrated tool for developing measuring strategies, you either implement company-specific measuring strategies or you optimize your inspection plans based on recommendations made by ZEISS.
Learn more
Calibration Control
Use Calibration Control (CC) for Calibration, Maintenance, or general Asset Management. Quickly and visually track equipment that requires Calibration or Maintenance using customizable highlighted grids, auto emails, or reports. Maintain histories with audit trails relating to equipment traceability, people, companies, related documents, attachments, certificates, & more.
Automate Calibration Control with custom or default barcode labels scanned by time-saver data entry dialogs to increase speed and traceability. Use the Report Designer for custom reports or modify existing reports.
ISO, FDA, & ANSI quality systems use CC to maintain compliance and effortlessly communicate that compliance to auditors and internal customers. Although CC grew up in a Manufacturing environment, it is also used in other industries like Metrology Services, Health Care, Aviation/Aerospace, Mining, Testing, Maintenance, Designer Engineering, Oil Wells, Distribution, Packaging, and others.
Learn more
OGP Measure-X
From creating part measurement routines to operating an OGP system in a production work environment, Measure-X® metrology software offers power without intimidation. Measure-X® features a full set of image processing and autofocus tools, geometric functions, ANSI/ISO tolerances, easy editing, and contour analysis. Compatible with touch probes, laser, and rotary indexers. Users can address more complex GD&T requirements such as profile, and true position of features when datum features of size allow mobility on the feature and the datums. The display and reporting capabilities with analysis provide both graphical, color-coded whiskers of deviation, and GD&T callouts on the part CAD.
Learn more
Renishaw MODUS
Renishaw's MODUS software provides a powerful platform for 5‑axis measurement. A configurable user interface allows native DMIS programs to be developed offline, drawing geometry, embedded dimensions, and tolerance data from CAD, with full simulation. The software includes certified algorithms for feature measurement, feature construction, and part alignment. Programs can be created offline directly from CAD with on-screen probe path verification. The CMM environment, the fixture, and the location of the part on the machine can all be defined, enabling full simulation of 5‑axis measurement programs. This minimizes CMM downtime as programs arrive at the machine ready to run, with little or no prove-out time required. The reporting capability of MODUS is extensive, including traditional CMM text reports with comprehensive user-defined formatting. Graphical reporting enables results to be displayed against the CAD model, including whisker charts or 3D form plotting for many features.
Learn more
